Elbow Crimped ORFS Fittings
24291 ORFS elbow fitting is known as flat face or O-ring face seal. And this tube fittings have been proved to be very effective in eliminating leakage at high pressures in hydraulic systems nowadays. 24291 fittings meet the requirements of SAE 1453 standard. Its popular color is white, yellow, and silver.
Click here to send e-mail!
-
Part no.: 24291(90 Degrees ORFS Female Flat Seat Crimp Type)
Material: YH tube fittings are available in steel(carbon steel), stainless steel(SS304 or SS316)
O-ring material: Viton
Packing: Nylon plastic; Corrugated Carton; Multiple plywood case
Payment: 30% TT in advance; 70% TT before shipment(common way)
Delivery: for stock products, with 5 days; new produced items 20 days(according to quantity and items)
-
Drawing
Technical Data
代号
PART NO.
螺纹E
THREAD E
胶管 HOSE BORE
尺 寸
DIMENSIONS
公称内径DN
标 号 DASH
C
S1
H
24291-08-08
3/16"X16
12
08
12
27
55
24291-20-20
1.11/16"X12
32
20
15.5
50
97
