BSP Female Plugs
Item 9B is instead of BSP female 60 degrees cone plug. This item is welcomed and highly accepted because of its good quality and reasonable prices. YH are manufacturing more than 10000 types of hydraulic fittings and adapters including BSP, BSPT, UNF, NPT, and metric threads. We are also willing to offer OEM services.
Click here to send e-mail!
-
Part no.: 9B(BSP Female 60 Degrees Cone Plug)
For Sales: Quality assurance for both products and after-sales service; Offer favorable prices; Environment friendly technology to protect the earth; OEM and ODM service available
For Quality: Material under strictly control when using; Products inspected 100% before finished; Production line tested by work team or data engineers at fixed period; before packed and loaded, products’ property and quantities tested; QC tam in YH Hydraulic
Market: products sold to North American; South American; Middle East; South Asia; Latin American mostly
-
Drawing
Technical Data Table
代号
PART NO.
螺纹
尺寸 DIMENSIONS
THREAD E
C
S1
9B-04
G1/4"X19
5.5
17
9B-06
G3/8"X19
6
22
9B-08
G1/2"X14
7
27
9B-10
G5/8"X14
8.5
27
9B-12
G3/4"X14
9
32
9B-16
G1"X11
11
38
9B-20
G1.1/4"X11
11
50
9B-24
G1.1/2"X11
12
55
9B-32
G2"X11
15
70
