Hydraulic Flange Adapter
1JFS instead of JIC male 74 degrees with s-series flange are popular producing in YH Hydraulic. YH has a highly knowledgeable and experienced technical sales team that works together to make sure you get the right products at the first time and fast. Flange fittings come in material of 45 carbon steel and stainless steel.
Click here to send e-mail!
-
Part no.: 1JFS(JIC male 74 degrees with s-series flange)
Products offered: complete items of adapter fittings; special dimensions and other standard products available under customers’ requirements
Samples: Less than 5pcs is free of charge according to stock condition
Thread types: JIC; metric; ORFS; BSP; BSPT; JIS; female; male
After-sales service: available
-
Drawing
Technical Data Table
代号
PART NO.
螺纹
法兰尺寸
FLANGE SIZE
尺寸 DIMENSIONS
THREAD E
1
d1
A
1JFS-08
U3/4"X16
1/2"
7.9
31.7
16.7
1JFS-10-08
U7/8"X14
1/2"
7.9
31.7
19.5
1JFS-10-12
U7/8"X14
3/4"
8.9
41.3
22
1JFS-12
U1.1/16"X12
3/4"
8.9
41.3
22
1JFS-12-16
U1.1/16"X12
1"
8.9
41.3
22
1JFS-16
U1.5/16"X12
1"
9.6
47.6
23
1JFS-16-12
U1.5/16"X12
3/4"
9.6
47.6
23
1JFS-16-20
U1.5/16"X12
1.1/4"
9.6
47.6
23
1JFS-20
U1.5/8"X12
1.1/4"
10.4
54
24.5
1JFS-20-16
U1.5/8"X12
1"
10.4
54
24.5
1JFS-20-24
U1.5/8"X12
1.1/2"
10.4
54
24.5
1JFS-24-20
U1.7/8"X12
1.1/4"
12.7
63.5
27.5
1JFS-24
U1.7/8"X12
1.1/2"
12.7
63.5
27.5
